System Patio Door

Include a strong and long lasting patio door in your home with increased security features. Patio doors slide open horizontally, so they require less space to operate. Through large panels of glass we can create bright and airy spaces with a large amount of natural light. Compared to other American window systems, it is highlighted by a higher safety standard. It can be used in both traditional and modern architecture.

Technical Specifications

  • Construction depth: 90 mm
    Number of chambers: Multi-chamber PVC profile system for enhanced insulation
    Glazing thickness: From 4 mm up to 32 mm, compatible with double and triple glazing options
    Maximum dimensions: Width up to 2,613 mm and height up to 2,503 mm, allowing large glazed surfaces with optimal daylight
    Maximum sash area: up to 5.64 m²
  • Thermal insulation: Uw values as low as 0.83 W/m²K (with 44 mm triple glazing 4/16Ar/4/16Ar/4)
    Sound insulation: up to 44 dB depending on glazing configuration
    Reinforcement: Steel reinforcement in both frame and sash (approx. 1.5 mm thickness) ensures stability and long-term durability
    Sealing system: Double gasket with concealed drainage for improved water tightness and performance
    Security: Equipped with multi-point locking and class D ABUS cylinder for increased burglary protection
